Stainless Steel Pipe Mill

Our stainless steel pipe mill is a complete production line designed to manufacture straight welded pipes from stainless steel raw materials. With the pipe mill you can produce pipes of various shapes (round pipe, square pipe, rectangular pipe) through cold roll forming, argon arc welding, and TIG welding technology. The stainless steel pipes can be produced from 6 to 508mm in outer diameter.

Steel Pipe Manufacturing Process:

Scrolling up→ Forming → Welding→ Grinding → Sizing→ Straightening→ Cutting→ Run out table →Inspecting→ Packing→ Warehouse

Model	Round pipe mm	Square pipe mm	Thickness mm	Working speed m/min
SS25	Ф6-Ф25	5x5-20x20	0.2-0.8	10
SS32	Ф6-Ф32	5x5-25x25	0.2-1.0	10
SS51	Ф9-Ф51	7x7-40x40	0.2-1.5	10
SS64	Ф12-Ф64	10x10-50x50	0.3-2.0	10
SS76	Ф25-Ф76	20x20-60x60	0.3-2.0	10
SS114	Ф38-Ф114	30x30-90x90	0.4-2.5	10
SS168	Ф76-Ф168	60x60-130x130	1.0-3.5	10
SS219	Ф114-Ф219	90x90-170x170	1.0-4.0	10
SS325	Ф219-Ф325	170x170-250x250	2.0-8.0	3
SS426	Ф219-Ф426	170x170-330x330	3.0-10.0	3
SS508	Ф273-Ф508	210x210-400x400	4.0-12.0	3

Note: We can design and manufacture pipe mills according to your requirements.
